Low Profile 90 Degree Rj45 Connector Rj45 Modular Jack Shielded

Name: Low Profile 90 Degree Rj45 Connector Rj45 Modular Jack Shielded
Brand: PHCONN
Price: 1 USD

Brand Name : PHCONN

Model Number : 1060-208041

Certification : IATF 16949 ISO 9001

Place of Origin : China

MOQ : MOQ 500- 5KPCS

Price : Negotiable price

Payment Terms : T/T

Supply Ability : 500K-1KK/Month

Delivery Time : L/M 3-4 weeks

Packaging Details : tray

Application : PCB,Audio & Video,networking,Telecom

Color : Black/White/OEM

Insulation resistance : 1000 megohms min @ 500 vdc

Keywords : rj45 connector/rj45 female connector/rj45 jack/rj45 socket

Housing : Thermoplastic plastics

Contact resistance : 50 Milliohms max

Voltage rating : 125 VAC RMS

Sample : welcome ask sample for testing

Contact Now

low profile rj45 connector 90 degree rj45 connector rj45 connector shielded

PHC52-1052-208007 Single Port Low Profile RJ45 Connector Without Magnetic jack modualr RJ45

ATTRIBUTE	ATTRIBUTE VALUE
TEMPERATURE	-40 to +85℃
GROUNDING OPTIONS	Panel Ground and PCB Ground
SHIELD PLATING MATERIAL	NICKEL
SHIELD EMI TABS	YES
SHIELD	METAL SHIELD
ROHS COMPLIANT	YES
PANEL STOP	NONE
PCB MOUNT ANGLE	SIDE ENTRY
PACKAGE	SMT
CONNECTOR & CONTACT TERMINAATES TO	Printed Circuit Board
NUMBER OF PORTS	1X1
NUMBER OF CONTACTS	8
LED OPTION	NONE
LATCH ORIENTATION	LATCH DOWN
HOUSING MATERIAL	PBT UL94V-0
CONTACT MATING AREA PLATING	GOLD FLASH PLATING
CONNECTOR TYPE	RJ45
CONNECTOR MATERIAL COLOR	BLACK

FAQ

Q: Are you trading company or manufacturer ?

A:We are factory.

Q: How long is your delivery time?

A: Generally it is 3-7 days if the goods are in stock. or it is 2-3 Weeks if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight..

Q: What is your terms of payment ?

A:TT/LC/DP/DA/Paypal/Western Union/MoneyGram

Low Profile 90 Degree Rj45 Connector Rj45 Modular Jack Shielded
